A12-181

Available items

  • Lead pin
  • Lead wire
  • Grounding terminal
  • Gear head
A12-181
A12-181
A12-181
A12-181

A12-181-01

Part number Diameter Length Voltage No-load speed No-load current Stall current Armature resistance Stall torque Max. efficiency Max. output
  ［mm］ ［mm］ ［V］ ［rpm］ ［mA］ ［mA］ ［Ω］ ［mNm］ ［％］ ［W］
A12-181-01 φ12 18.1 9.0 8,860 5 138 65.2 1.24 65.6 0.289
